Productions at highest level
ATV FULL BROADCAST
Combine automatic cameras with manually operated cameras
Raise the emotion to the maximum with a monitoring of the game to the smallest detail with close-up cameras
Live stream wherever you want
The content is yours, you decide how to deliver your live streaming to your fans and audience
Automatic and manual graphics
Enhance your productions with advanced statistics
Replays
Decide when to show the most important actions once again
Small production crew: 5 people at most
Minimize your crew in each one of your productions
Huge cost-reduction
Expande tu mercado a nuevas producciones y competiciones gracias a la reducción de costes de producción
A revolution in broadcasting productions
Imagine a production with different camera positions, close-ups, replays, advanced graphics, and commentator. Now imagine that you are able to do all this with a small crew. Revolutionary, isn’t it?
Specifications
- Image capture
2x4K
- Image quality
Broadcast with high dynamic range
- Camera position
Multicamera
- Frames per second
50/60
- Maximum quality output
FullHD
- Output formats
RTMP, SRT, TCP, UDP, MPEG4
- Maximum outputs
Up to 5 at 50/60 fps
- Additional cameras
Up to 2 4K or 4 FullHD
- NDI input cameras
Up to 2 FullHD
- SDI outputs
1 optional (additional hardware)
- Type of production
Manual and/or automatic
- Graphics
Included
- Additional software for live productions
Advanced graphics and replays
Please, keep in mind that some of the described functionalities require different computing capabilities, and due to the potential number of combinations, not all configurations are supported. Contact us for more information
Example of a real ATV FULL BROADCAST production
Peruvian women’s first division soccer league
Technical resources
1 Automatic Mastercam
2 Side cameras
2 Close-up cameras*
1 Vmix server
1 Audio mixer Behringer
*operated manually
Human resources for a 5 cameras production
1 Director – Camera switcher
2 Close-up camera operators
1 Replays operator
1 Commentator
Baseball production for ESPN
Technical resources
4 ATV individual cameras*
2 Virtual cameras
1 ATV server
1 Vmix server
1 SportZcast
1 Audio mixer Behringer
*operated manually
Human resources
1 Director - Camera switcher
2 Close-up camera operators
1 Replays operator
1 Sound technician
1 Comentator
